AirOxi Tube - Root Blowers

AirOxi Tube - Root Blowers

Root Blowers are the most suitable type of blowers for aaquaculture applications. Their rugged construction and heavy twin lobes can resist water head and so continue to give good air flow even at water depths of 2 mtr. and more. They are available in sizes of 3 HP and above.

TECHNICAL DATA FOR 5 HP BLOWER

MODEL : RIC–014(5HP)
CONSTRUCTION : CI
COOLING : AIR COOLED
FLOW : HORIZONTAL
CAPACITY : 300 M3/HR
PRESSURE : 0.3 KG/ CM2
BLOWERRPM : 1933 RPM
REC.POWER : 5HP / 1450 RPM
DRIVE : V BELT DRIVE

TECHNICAL DATA FOR 7.5 HP BLOWER

MODEL : RIC–016(7.5HP)
CONSTRUCTION : CI
COOLING : AIR COOLED
FLOW : HORIZONTAL
CAPACITY : 400 M3/HR
PRESSURE : 0.3 KG/ CM2
BLOWERRPM : 1700 RPM
RECOMMENDED POWER : 7.5HP / 1450 RPM
DRIVE : V BELT DRIVE

TECHNICAL DATA FOR 10 HP BLOWER

MODEL : RIC–016(10HP)
CONSTRUCTION : CI
COOLING : AIR COOLED
FLOW : HORIZONTAL
CAPACITY : 500 M3/HR
PRESSURE : 0.3 KG/ CM2
BLOWERRPM : 2000 RPM
RECOMMENDED POWER : 10HP / 1450 RPM
DRIVE : V BELT DRIVE

TECHNICAL DATA FOR 15 HP BLOWER

MODEL : RIC–019(15HP)
CONSTRUCTION : CI
COOLING : AIR COOLED
FLOW : HORIZONTAL
CAPACITY : 800 M3/HR
PRESSURE : 0.3 KG/ CM2
BLOWERRPM : 1900 RPM
RECOMMENDED POWER : 15HP / 1450 RPM
DRIVE : V BELT DRIVE

TECHNICAL DATA FOR 20 HP BLOWER

MODEL : RIC–020(20HP)
CONSTRUCTION : CI
COOLING : AIR COOLED
FLOW : HORIZONTAL
CAPACITY : 1000 M3/HR
PRESSURE : 0.3 KG/ CM2
BLOWERRPM : 1900 RPM
RECOMMENDED POWER : 20HP / 1450 RPM
DRIVE : V BELT DRIVE

MACHINE OF CONSTRUCTION

ROTOR PAIR : SG IRON
CASING (BODY) : CI-IS210 FG260
COVERS : CI-IS210 FG260
OUTER COVERS : CI-IS210 FG260
GEAR PAIR : Alloy steel / Hardened & Ground
BEARINGS : ZKL/SKF

FOLLOWING ACCESSORIES INCLUDED

Suction Silencer : Suction filter
V pulley for Machine & Motor : Base frame with slide rail
Pressure gauge : T connection for pipe fitting
V belt set : Belt guard
Tire mounting assembly flame :
