Ferrari - Model FPC -Semi-Automatic Transplanter With Plastic Film Layer
FERRARI FPC is the semi-automatic transplanter with plastic film Layer, able of Laying the plastic film both in polyethylene and biodegradable, fixing it well to the ground and transplanting square pressed blocks, with an average yield of 5,000 plants / hour per element and one operator every two rows. The frame is perimetral with a parallel linkage and can be of different sizes, based on the width of the plastic film. Each element is equipped with a belt that conveys the plants towards a synchronized system of grippers. These grippers separate each plant and insert it into the hole made in the plastic film by the perforator and then in the furrow traced by the ploughshare, which operates under the film. The general electronic management guarantees a high production capacity, combined with ease of use and a high quality transplant.
- Versions: 3 points -self-propelled
- Frame: single bed
- Minimum inter-row spacing: 23 cm
- In-row spacing: electronically adjustable from 10 to 100 cm
- Main features: parallel linkage - stainless steel roller - electronic gearbox - row switch-off device - electronic adjustment plant position in the ground
Maximum Productivity Per Operator
Mulching transplanter capable of spreading both polyethylene and biodegradable plastic film, fixing it to the ground, drilling it and transplanting it with cubic-compressed clods in a semi-automatic manner with average yields of 5,000 plants/hour per row.
Per Plastic Film
- Width of 1400-1600 mm
- Width of 1600-1800 mm
- Width of 1700-1900 mm
In the case of widths other than those indicated, special frames can be manufactured
- Device for cutting hydraulic film with removal of obstructive material.
- Pneumatic cylinder for the control of film pressure.
- Hydraulic lifting of the machine for inspection.
- Rear platform for cargo pallet.
On each row there is an in feed strip that separates one clod from the other and inserts it, through the hole made by the perforator in the plastic film, into a groove traced by a ploughshare operating simultaneously under the sheet. The operation is managed by a synchronised gripper system.
The real innovation of this machine lies in its extraordinary production capacity thanks to its general electronic management, in addition to the distance that can be set via the digital keyboard.
