Reporoa Engineering (1982) Ltd
Reporoa Herdflow - Sheep and Goat Backing Gate
Touch Screen Control Located on gate control box for fault finding, adjusting settings and manual operation.
Most popular related searches
- Button Controls Located in shed and on gate. Controls: up, down, forward, reverse, pulse forward and wash.
- Pulse Forward Auto Stop High Lift Gate travels forward a predetermined (1m to 10m adjustable) distance then stops until commanded again.
- Two Speed Forward & Reverse High Lift Gate can travel at either fast or slow speeds in both forward & reverse directions.
- Gate Lowering As High Lift Gate is lowered it pauses at approx. cow back height to allow cows time to move away before lowering fully to the ground.
- Audible Alarm An electronic alarm is located in the control box on the gate to sound when the gate is moving. Provides audible prompt for cows and advises operators which mode the gate is operating in.
- Electrical & Mechanical Installation High Lift Gate is installed and operational provided electricity is supplied to front of yard. Includes "I" beam (top rail) for gate to run on. Post must be correct height, straight and parallel.
- High/Low Rail Options High Lift Gates built for 1200mm to 1700mm high top rail.
- Anti De-Rail Design Drives on top of "I" beam and clamped on with front and back side mounted idler wheels when "I" beam used.
- Programmable for Variable Wash Can be programmed for gull wing wash, forward or reverse wash.
- Pre-wired plug & Play Electrical system Gate is 100% pre-wired which allows the installer to commission gate, check all functions & train users on final day of installation.
