H&S - Single Axle Running Gear
H&S models 410, 412, 415, 612, 614, and 617 have L-shaped front spindles with structural bracing to withstand high stresses from shock loads. The H&S heavy running gears – models 415 through 622 – utilize thrust bearings to assure dependable, smooth turning and straight trailing. The tele-pole is made of structural tubing and the mounting plates have wide spacing between them to reduce sway and increase the strength of the pole. The C-Section reach provides both strength and flexibility without rotating collars.
-
King Pin, Hitch Pin, Spindles, Tie Rod Ends and Tie Rod Steering Pivot Point are all wear protected by replaceable oil impregnated steel bushings and are greaseable as well.
-
Full Contact Turn Stops distributes the pressure exerted in tight dragging turns along the bolster face – this reduces the possibility of bunk damage or collapse.
-
Running gears from 12 ton on up have 4-bolt brake flanges as standard equipment so that optional hydraulic surge brakes may be installed.
-
The tie rod is positioned behind the bolster on all models and is a one-piece design that reduces the number of wear point that could change the toe-in and tracking.
-
The spring assist is standard on all models and is adjustable from a light assist to full support.
-
Front and rear stake pockets wear pockets are standard on ALL MODELS!
- CAPACITY : 10 TON
- WEIGHT W/TIRES : 1126# w/12.5L
- TREAD WIDTH : 80″
- SPINDLES : 2″
- HUBS : 6 BOLT
- BOLSTER : 3″ x 8″
- C-REACH : 7 GAUGE
- WHEEL BASE : 119″ TO 159″ IN 10″ INCREMENTS
- STANDARD WHEEL : 15 x 10
- WHEEL OPTIONS : N/A
- BRAKES : N/A
- BACK HITCH : YES
- TELESCOPING POLE : 77″ FIXED, EXTENDS TO 89″
- CAPACITY : 12 TON
- WEIGHT W/TIRES : 1190# w/12.5L
- TREAD WIDTH : 80″
- SPINDLES : 2.25″
- HUBS : 8 BOLT
- BOLSTER : 3″ x 8″
- C-REACH : 7 GAUGE
- WHEEL BASE : 119″ TO 159″ IN 10″ INCREMENTS
- STANDARD WHEEL : 15 x 10
- WHEEL OPTIONS : 16.1 x 11 22.5 x 8 22.5 x 13.5
- BRAKES : OPT. HYD. SURGE
- BACK HITCH : YES
- TELESCOPING POLE : 77″ FIXED, EXTENDS TO 89″
