Yigitsan - Model COPE 1200 -Trailed Automatic Potato Planter
It can be easily used with tractors between 70 and 100 HP. Potato hopper: Hydraulic hopper, 2 hydraulics. Tractor hydraulic: 2 control valves, single effect required. Filling height: 90–130 cm. Planting capacity: 2.2 ha/h. Planting length: One unit approximately 5,000 m. Planting system: Marathon. Rows: 4, each planting unit can be mechanically shut off. Row spacing: 75 cm standard, 80–85 cm and even 90 cm possible. Plant spacing: 15–43 cm, 24-step adjustment. Cup shovels: Standard four types, 33–55 cm (for seeds under 33 cm or 55 cm plastic seed pieces available as accessory).
Planting depth: Full planting depth (each row has a parallel gauge wheel and furrow opener). Cover discs: 3 per row, adjustable in dimensions, dual-bearing standard with scraper unit, contact pressure adjustable; each disc individually fixed in transport position for very short planting distance. Furrow opener: Each opener has full shoe. Vibrator: Mechanical, adjustable in 6 steps (for each row). Cup chain: Maintenance-free and automatically tensioned. Chassis: Hydraulic lift and transport adjustable (for heavy-foot and swampy soil), 3-step working or transport position. Tire equipment: Rear 12.5/80-18, front 7.50-16. Drive: Heavy chain with automatic duplex tension. Bearings: Maintenance-free ball bearings. HP requirement: From 50 HP.
- Length: 325 cm
- Width: 350 cm
- Height: 140 cm
- Weight: 2980 kg
- Planting Distance: 75–80–85–90 cm
- Coverage per Hour: 13–14 da/h
- Hopper Capacity: 3000 kg
- Operating System: Mechanical
- Dimensions: 350/260/350
