NEW! 2018 - Heavy Duty 16 Ton Hydraulic Farm or Construction Dump Trailer with 9800 lb Load Capacity Video

Berkelmans Welding and Manufacturing Inc.

16 Ton Farm or Construction Dump Hydraulic Trailer

8 bolt hub and 12000 lb spindle and hub load rating
3” replaceable spindles
7.5 ft wide x 14 ft. long x 4 ft. high with board extension
8”x 4” x 1/4'” tube main frame
3/16 ” formed long sills welded 100% to the floor
¼ ” plate floor bent with the sides as one pan
12000 lb drop leg trailer jack
Swivel clevis style hitch
Hydraulic tailgate that lift 40” above sides when open
Tail lights and reflective tape
4” channel post
3 x 4x.188 tube top railing
Under body telescopic hoist
55 degree dump angle
Needs 17 feet of headroom to dump
82” to top of box with no board extension and 94” with the board in
All seams and post are 100% welded
Chemical wash, automotive type metal treatment and primer, top coat with your choice of colour
15.5 cubic yard capacity
101 inches wide outside box
Trailer weight is approximately 6000 lbs.
Standard 500/22.5 tires with 9800 lb load capacity

We believe in manufacturing a trailer that can handle normal use, and maybe even a little abuse, and still function as it should. Our experience has taught us the right way to build trailers. We use only high grade materials and constantly monitor the quality of the trailers throughout the manufacturing process. That's why you'll find that a trailer from Berkelmans Welding and Manufacturing Inc. will normally outlast and outperform other trailers. You have to use quality raw materials and maintain high manufacturing standards in order to consistently produce quality trailers. That's exactly what we do at Berkelmans Welding and Manufacturing, Inc. Delivery available throughout Canada and USA
