Brooks Brothers Trailers products

Capacity: 13,000 lbs. GVWR – Calculated at 15% Weight Transfer to Tow Vehicle. 10,200 lbs. Load Capacity. Dimensions: Length Adjustments: 20’ / 25’ / 30’. Cargo Bed: 9’L x 64”W x 15”H. Overall Width: 89”. Bolster Height: 45”. Axles: 6000 lbs. Tandem Straight Axles – (Optional Axles: 7K & 8K). Electric Brakes All Wheels. 3500 lbs. 5 Leaf Slipper Springs,. Reinforced Spring Hangers with 3” Structural C-Channel Crossmenber. (4) four – ST235/80R16 LR-E Tires, Capacity 3,042 lbs. each, Single Wheel Application. (4) four – 16” x 6” Single Wheels (8 Hole on 6 1/2″ Bolt Circle). (1) Pair – Mud Flaps.

Capacity: 13,800 lbs. GVWR – Calculated at 15% Weight Transfer to Tow Vehicle. 10,200 lbs. Load Capacity. DIMENSIONS: Length Adjustments: 24’/31’/38’. Cargo Bed: 130”L x 90”W x 10”H. Overall Width: 93”. Bolster Height: 48”. Axles: 6000 lbs. Tandem Straight Axles – (Optional Axles: 7K & 8K). Electric Brakes All Wheels. 3500 lbs. 5 Leaf Slipper Springs,. Reinforced Spring Hangers with 3” Structural C-Channel Crossmenber. (4) four – ST235/80R16 LR-E Tires, Capacity 3,042 lbs. each, Single Wheel Application. (4) four – 16” x 6” Single Wheels (8 Hole on 6 1/2″ Bolt Circle). (1) Pair – Mud Flaps.

Our reel and pole trailers can be outfitted with a variety of different tensioning brakes and hydraulic take-up units.  Our reel trailers can be configured for single or multiple reels.  Please contact our sales staff to discuss your specific needs.

This 2RT has extendable reel gear for use on railways and Metro systems.

Turret turned in tilt position for photos only. Turret should only be used when reel is in the fully loaded position.

Ask about our various designs and power-units. Heavy Duty Bronze bearing. 2 7/8` Reel bar with crossarms. May be equipped with hydraulic retriever and brake assembly. Fork pockets.
