- Johnson - Model 1000RS - 10 Inch Rear ...
Most popular related searches
- 10′ blade lengths
- Blade tilts 15 degrees left and right for slope cuts.
- Blade angles 40 degrees left and right
- Requires one additional remote to operate rear steer functions.
- All hydraulic functions can operate from one remote. Simply tell us your setup prior to purchase.
- To operate the functions of blade angle, tilt, and lift, the 1000RS comes equipped with one of the two following options:
- 3 button handle (operates off of one remote)
- 3 switch control box (operates off of one remote)
- Concrete weight & box scraper ends are standard with each model.
- Reversible / replaceable high carbon steel cutting edge.
- Deep Tri Rib tires have excellent side bite traction.
- Excellent blade to ground clearance.
- Storable hitch jack.
- Safety chain is included.
- Blade: Blade Angle 40°, Blade Height 17", Blade Length 10`, Blade Tilt 15°, Blade to Ground Clearance 12"
- Tires: Two Tri Rib 5.00 x 15", 4 ply
- Hubs and Spindles: 1500# 4 bolt
- Total Weight: 2240#
- Tongue Weight: 590#
- Transport Width: 8` 5"
- Cutting Width at 45° Angle: 7` 1"
- Overall Length: 18"
- HP Range: 25 – 100
