Quadco - Model S35.a -Seeder
Quadco 56″ mower mulches vegetation into fine material, discharging directly to the ground. The drum mower is designed to fit a wide range of applications–from light brushing to heavy full tree mulching. Operating costs are minimal with the low-maintenance, belt-driven, 26 staggered-tooth drum, which comes with a choice of rotatable teeth to fit the application– reversible, beaver, concave, or carbide. Simple and easy to use, only using 3 hydraulic lines – 2 additional hydraulic lines are required for the optional rotator.
Design
The Bracke S35.a is available in two and three-row versions and can be attached to all of our scarifiers as well as mounders and trenchers. The Bracke S35.a senses the prime mover’s forward motion and regulates the seed feed accordingly. The seed feed can also be synchronized with the scarifier, so that only scarified soil is seeded.
Machine control
The control system, is based on a PLC platform and communicates over a CAN bus. The seeder is fitted with sensors that send information to the control system about, for example, the prime mover’s speed. For the two or three sowing channels, or seeding rows used, information is provided in real time on the number of seeds sown for each individual channel. From the display, the operator sets functions, such as the number of seeds sown per meter and intermittent sowing. The control system sounds an alarm if problems arise in the seed feed. Settings are made and information retrieved via the display in the cab. All units communicate over the CAN bus. The control system keeps track of the number of seeds sown, for both individual channel and in total, and the distance sown.
