Bednar - Model Swifterdisc XO_F -Short Compact Disc Cultivator

VERSATILITY
Its true name. See for yourself.

Stubble cultivation after harvest
Stubble cultivation is one of the most important field operations. According to the proper agricultural procedures, it should be done as soon after harvest as possible. For this operation, SWIFTERDISC XO_F can be equipped with notched or aggressive discs with a diameter of 520 × 5/ 560 × 5 mm, providing excellent cutting, mixing with soil and incorporation of crop residue. The rear packers consolidates soil and close the soil profile to ensure even emergence of weeds and unwanted cereal seeds.

Seedbed preparation
The optimal disc diameter in combination with the high working speed provide a high circumferential speed of the discs, which leads to excellent crumbling and mixing effect of the disc section. If you are planning to use the disc cultivator for soil preparation more frequently, we recommend adding the front Crushbar levelling bar to SWIFTERDISC XO_F, for levelling unevenness and breaking the rough furrow.

INTEGRATED AXLE AND PACKER LAYOUT
Extremely stable even at higher working speed.
The two-row layout of rear packers provides better stability at high speed than one row design, and also eliminates the gap in disc cultivators with two rollers in one row. The integrated axle ensures even distribution of the machine weight and eliminates its swaying. Moreover, it ensures safer transport and reduces the turning radius of the tractor with the cultivator at headland.

EASY WORKING DEPTH CONTROL
Mechanical or comfortable hydraulic setting.
The working depth of the disc cultivator is easily set on the rear rollers. If the machine is equipped with front support wheels, they are set automatically using the mechanical connecting rods.

TRASH CUTTER
A cutting roller for tough crop residue.
The SWIFTERDISC XO_F cultivator can be equipped with the Trash Cutter roller in the front, an ideal choice for cutting crop residue and hard stalks. Such cut crop residue decomposes better in soil and facilitates subsequent soil cultivation, preventing machine clogging.

CRUSHBAR LEVELLING BAR
Use the disc cultivator for soil preparation as well.
To increase the all-year-round utilisation, SWIFTERDISC XO_F can be equipped with the hydraulically controlled Crushbar levelling bar in the front. This combination provides perfect soil profile levelling, clod crumbling, and soil preparation.

ALFA DRILL SEEDING UNIT
Establishing catch crop in one pass.
The SWIFTERDISC XO_F cultivator can be equipped with the BEDNAR ALFA DRILL seeding unit while in production, for seeding catch crop and small-seed plants during stubble cultivation, all in one pass. The time and fuel savings are considerable. The seeding unit has a capacity of 400 litres.

HYDRAULIC DRAWBAR
Perfect terrain contouring – always and anywhere.
The SWIFTERDISC XO_F disc cultivator is equipped with a hydraulic drawbar. We use this technical design as it facilitates the connection to the tractor, and above all, improves the quality of work because the disc cultivator perfectly contours any terrain unevenness.

SAFE TRANSPORT
Excellent stability and high working speed.
The integrated axle mounted near the tractor provides excellent driving abilities. The working sections are folded upwards; frames are comfortably secured using hydraulic locks. A smooth and safe transportation with a transport width of 3 metres and working speed up to 20 km/h.
