PronovostModel P-505 -Snow Removal Equipment

SHARE

The P-505 is a robust piece of equipment designed for effective snow removal, ideal for homeowners and public works use. It boasts a capacity of 2.5 tons, with generous interior dimensions measuring 60 by 94 inches, making it adaptable for various snow clearing needs. The equipment can be equipped with a hydraulic pump, a battery holder, and comes with various tire options, including models P-505T and P-505M. The design allows for efficient storage and operation across challenging terrains. These features collectively enhance the versatility and functionality of the P-505 snow removal unit, ensuring a reliable solution for efficient performance during winter months. Adaptations and specifications may evolve over time to meet emerging industry requirements and technology advancements.

Most popular related searches
  • Robust chassis and reinforced deck (box rails under the deck).
  • Strong, removable profiled panels.
  • Hinged side panels (certain models).
  • Automatic rear panel opening mechanism (except on P-503).
  • Optional grain chute on rear panel.
  • Optional maximum tilt angle auto stop on certain models.
  • Optional board pockets on certain models.
  • Swivel hitch or ball receiver.
  • Cylinders and hydraulic hoses with quick disconnects.
  • Electric hydraulic pump optional.

  • Capacity: 2.5 tons
  • Interior dimensions: 60" x 94"
  • Dumps: Rear
  • Axle: Tandem
  • Gross vehicle weight rating: 2.5 tons
  • Interior box dimensions: 60" x 94"
  • Bed thickness: 3/16"
  • Side panels: 14" x 12G
  • Front / back panel: 19" x 12G
  • Removable panels: 4
  • Rear panel opening: Automatic
  • Platform height: 29 1/2"
  • Overall length: 139"
  • Overall width: 64"
  • Overall height: 52 1/2"
  • Free height at maximum tilt: 15"
  • Total height at maximum tilt: 103"
  • Tread width c/c: 53 1/4"
  • Dumping angle (back): 47°
  • Axles: Tandem
  • Hubs: 5 bolts
  • Hub capacity: 2500 lbs
  • Spindles: 2"
  • Wheels: 4
  • Wheels dimensions: 12" x 8.5"
  • Included tires: Turf-Saver 23 x 10.5 x 12"
  • Optional tires: Multi Trac 23 x 10.5 x 12"
  • Hitch : clevis/swivel: Inclus
  • Jack: Included
  • Cylinder(s): 1 double acting
  • Total weight (approx.): 1560 lbs / 708 kg

Design and specifications subject to change without notice.
